INSTALLATION WARNING
MukaTech heaters range from 5.5kW to 13kW. Each tier requires a different electrical setup. Match your model to the requirements below to ensure a safe installation.
| Heater Series | Power Rating | Max Amperage | Required Cable | Required Breaker |
|---|---|---|---|---|
| NX13 Series | 13.0 kW | 56.5 - 59.1 Amps | 6mm - 10mm Pure Copper | 63A Double-Pole |
| 6.0kW - 8.5kW Series (SG01, Q80, BSJ-A80) |
6.0 kW - 8.5 kW | 30.4A - 36.9A | 4mm - 6mm Pure Copper | 40A - 50A Single-Pole |
| W55U / 5.5kW Series | 5.5 kW | 23.9 Amps | 2.5mm / 4mm* | 32A Single-Pole |
The Model NX13 pulls up to 13.0kW of power. This is significantly more than a standard 3kW geyser. Standard domestic wiring WILL OVERHEAT if not upgraded correctly.
60 Amp
Dedicated single-pole breaker in your DB Board.
6mm² - 10mm²
Twin & Earth copper cable. Never use 2.5mm².
An undersized 32A breaker will trip within seconds of the heater reaching maximum temperature.
Thin or substandard cables will melt under high current loads, posing a critical fire risk to your home.
Any damage caused by improper electrical supply or incorrect cable thickness is not covered under warranty.
All Anlabeier units must be installed by a Certified Electrician. Incorrect wiring is the leading cause of E1 and E4 faults.
Ensure your wiring matches your selected power range to avoid "E1" or "E4" faults.
| Power Range | Model Examples | Required Breaker | Required Cable |
|---|---|---|---|
| 5.5kW Series | TPS-32N1 (With Pump), W55U, RSB-55H | 32 Amp | 4.0mm² |
| 6.0kW Series | SG01-60 Series | 40 Amp | 4.0mm² - 6.0mm² |
| 6.0kW - 8.0kW | Q80, BSJ-A80 | 40A - 50A | 6.0mm² |
| 8.0kW - 13.0kW | NX13, HY-80 | 60A - 63A | 6.0mm² - 10.0mm² |
If voltage is low in your area, you may need to select a higher power grade or decrease water flow to reach desired temperatures. Important: Always ensure your wiring matches your selected power range to avoid "E1" (Leakage) or "E4" (Dry Burn) faults.
